ONESIA Rama Series 3P/3P ONLINE UPS 40kVA

Capacity : 40kVA
Spesifikasi Teknis : ±5 - 15 menit
Deskripsi : Input Nominal Voltage 3 x 380VAC/400VAC (3Ph + N), Acceptable Voltage Range 165VAC - 280VAC (Ph-N), 285VAC - 485VAC (Ph-Ph), Frequency 50/60 Hz +- 10 %, Inverter Nominal Voltage 3 x 380VAC/400VAC (3Ph + N), Total Harmonic Distortion (THDv) less than 2% (Linear Load), less than 5% (Non-linear Load), Waveform Pure Sinewave, Static Bypass Voltage 176VAC - 264VAC (Ph-N), 304VAC - 456VAC (Ph-Ph), Transfer Time 0ms, Admissible Overload 0% - 150% continuous working, 150% - 180% 60 min-5 min, more than 180% 5 min, Maintenance Bypass Type without interruption, Maintenance Bypass Voltage 3 x 400V (3Ph + N), Maintenance Bypass Frequency 50/60 Hz, Battery Charging Method CC/CV, Battery Precision +-1%

Lokasi Pembelian Lokasi Pembelian

ONESIA Rama Series 3P/3P ONLINE UPS 40kVA

Rama Series 3P/3P ONLINE UPS 40kVA adalah perangkat UPS dengan kapasitas 40kVA, menawarkan perlindungan daya stabil dan handal menggunakan teknologi dual conversion dan mode ECO. Dirancang untuk aplikasi industri dan komersial, UPS ini memastikan pasokan daya yang konsisten dan aman dengan waktu pengisian baterai cepat.

Spesifikasi

SKU

· RA-40

Brand

· ONESIA

Kategori

· UPS

Capacity

· 40kVA

Spesifikasi Teknis

· ±5 - 15 menit

Deskripsi

· Input Nominal Voltage 3 x 380VAC/400VAC (3Ph + N), Acceptable Voltage Range 165VAC - 280VAC (Ph-N), 285VAC - 485VAC (Ph-Ph), Frequency 50/60 Hz +- 10 %, Inverter Nominal Voltage 3 x 380VAC/400VAC (3Ph + N), Total Harmonic Distortion (THDv) less than 2% (Linear Load), less than 5% (Non-linear Load), Waveform Pure Sinewave, Static Bypass Voltage 176VAC - 264VAC (Ph-N), 304VAC - 456VAC (Ph-Ph), Transfer Time 0ms, Admissible Overload 0% - 150% continuous working, 150% - 180% 60 min-5 min, more than 180% 5 min, Maintenance Bypass Type without interruption, Maintenance Bypass Voltage 3 x 400V (3Ph + N), Maintenance Bypass Frequency 50/60 Hz, Battery Charging Method CC/CV, Battery Precision +-1%

Keterangan Lainnya

· Garansi 12 Bulan

Type/Model

· RA-40
